LED outdoor spotlight high-voltage AV220V 5W 10W 16W 25W outdoor waterproof IP66 floodlight garden facade spotlight lawn lamp pole lamp

Item No.：LA-RF7-5WH/10WH/16WH/25WH
Input Current：AC220-240V
Power/LED(Watts)：2.5W/5W/10W/16W/25W
Power suppy unit：Integated /Triac/PWM/0～10V/DALI
Beam Angle［θ50%］：13.1°/18°/25.7°/41.3°
Color Temperature：2700K/3000K/3500K/4000K/R/G/B
control method：ON/OFF/Triac/PWM/0～10V/DALI/DMX512
Outgoing line ［CM］：100cm
Body Material：Aluminium+ tempered glass+#316 Stainless steel screw+with Honeycomb
Product Size［MM］：98*46*57mm/70*46*57mm/106*71*80mm/130*89*100mm/155*103*120 mm
IP level：IP66
INQUIRY

Features：

1. The light source of the lamp adopts LED chip, the light color is pure, and the CRI is more than 90;

2. The lamp body adopts aluminum CNC machining + aluminum radiator structure, the surface is sprayed with Aksu outdoor paint, and the double-layer coating process.

3. Various angles to choose from, uniform illumination

4. The light source of the lamp is deeply hidden, and the cut-off angle is 40°;

5. Install anti-glare honeycomb;

6. The lamp structure is mini and exquisite, suitable for use in various places such as construction and gardens.

7. The ground plug/shade is optional and needs to be purchased separately;

LED garden light 10W (1).jpg

Item No.	LA-RF7-5WH	LA-RF7-10WH	LA-RF7-16WH	LA-RF7-25WH
Input Voltage	AC220-240V	AC220-240V	AC220-240V	AC220-240V
Power/LED(Watts)	5W	10W	16W	25W
Power suppy unit	Integated/Triac/PWM/0～10V/DALI
Beam Angle［θ50%］	13.1°/18°/25.7°/41.3°	7°/15.6°/22°/31.5°/42.1°	12.8°/21.1°/31.4°/41.5°	15°/24°/36°/50°
Color Temperature	2700K/3000K/3500K/4000K
Body Material	Aluminium+ tempered glass+#316 Stainless steel screw+with Honeycomb
Product Size［MM］	984657mm	1237280.5 mm	14691.5100.5mm	155103120 mm
IP level	IP66	IP66	IP66	IP66
control method	ON/OFF,Triac,PWM, 0～10V,DALI,DMX512
